MIL-C-17F COAXIAL CABLE                           RG型同轴电缆

●导体使用单支或绞合镀锡或裸铜

●PE绝缘，符合ROHS环保标准

●PVC护套，符合ROHS环保标准

●镀锡或裸铜编织屏蔽

●用于传输系统或单项控制系统

●Solid or stranded ,tinned or bare copper conductor

●PE insulation, comply with ROHS environmental standard

●PVC jacket , comply with ROHS environmental standard

●Tinned or bare copper wire braid shield

●For use with communication and signal control systerm

导体

CONDUCTOR

绝缘

INSULATION

编织

BRAID

护套

JACKET

特性阻抗

CHARACTERISTIC

IMPEDANCE

 (Ω±5)

规格

AWG

构造

CONSTR-

UCTION

(No./mm)

外径

  DIA.

(mm)

绝缘厚度

INSULATION

THICKNESS

(mm)

外径

O.D.

(mm)

构造

CONSTRUCTION

(No./No./mm)

护套厚度

JACKET

THICKNESS

(mm)

外径

O.D.

(mm)

RG-6/U

1/1.024

1.024

1.79

4.60

24/7/0.12

1.16

7.40

75

RG-29/U

1/0.813

0.813

1.07

2.95

16/7/0.12

0.64

4.70

50

RG-58/U

1/0.813

0.813

1.07

2.95

16/7/0.12

0.76

4.95

50

RG-58A/U

19/0.18

0.90

1.03

2.95

16/7/0.12

0.76

4.95

50

RG-59/U

1/0.643

0.643

1.53

3.70

24/6/0.12

0.99

6.15

75

RG-62/U

1/0.643

0.643

1.53

3.70

24/6/0.12

0.99

6.15

75

RG-174/U

7/0.16

0.48

0.51

1.50

16/5/0.10

0.32

2.54

50
